Compact Desktop Network Appliance with Intel Celeron 3865U

Intel® Celeron 3865U 1.8GHz Dual Core processor
8x GbE RJ45, 2 x GbE SFP(Optional), 1x RJ45 Console Port
Max. 8GB DDR3 1600MHz SO-DIMM
1x Mini-PCIe Socket (PCIe/USB2.0 Signal)
Mini Desktop Form Factor
2x USB 2.0, 1x VGA

　　The NC-8210, powered by the Celeron 3865U processor, is a desktop form factor network appliance designed for entry-level network security, gateway or vCPE.

Intel® Celeron 3865U 1.8GHz Dual Core processor
8x GbE RJ45, 2 x GbE SFP(Optional), 1x RJ45 Console Port
Max. 8GB DDR3 1600MHz SO-DIMM
1x Mini-PCIe Socket (PCIe/USB2.0 Signal)
Mini Desktop Form Factor
2x USB 2.0, 1x VGA

Model No. NC-8210
Form Factor Desktop
Platform Processor Options Support Intel Celeron 3865U 1.8G Dual Core processor
CPU Socket BGA1365
Chipset SoC
Security Acceleration N/A
BIOS AMI 64Mb Flash ROM
System Memory Technology 1066/1333/1600MHz DDR3
Max. Capacity 8GB
Socket 1* SODIMM DDR3 Slot
Networking Ethernet Ports 8x Intel WG-i211 10/100/1000，
2 x Intel Ethernet Controller I350-AM2(Optional)
Bypass -
I/O Interface Reset Button -
LED Power/Storage
Power Button -
Console 1x RJ45
USB 2*USB2.0
LCD Module -
Display 1x VGA
Power Input Desktop Adapter
Storage HDD/SSD Support 1x2.5HDD/SSD
Onboard Storage 1x m-SATA
Expansion PCIe -
Mini-PCIe Yes
Miscellaneous Watchdog Yes
Internal RTC with Li Battery Yes
TPM -
Cooling Processor CPU fan
System 1x cooling fans
Environmental Parameters Temperature 8℃～45℃/-20℃～70℃
Humidity 0-95% (relative humidity; non-condensing)
System Dimensions (WxHxD) 265x44x215mm
Weight 2.1 kg
Package Dimensions (WxHxD) 285x540x235mm
Weight 3.3 kg
Power Type/Watts -
Input -
Approvals and Compliance CE, FCC Class B


  • DocumentDocument

    1. V1:
      • /uploads/soft/190828/NC-8210.pdf ' target='_blank'>Datasheet
      • ' target='_blank'>User Guide
      • ' target='_blank'>3G/4G USB Modem Compatibility List
      • ' target='_blank'>Quick Installation Guide
    2. V2:
      • ' target='_blank'>Datasheet
      • ' target='_blank'>User Guide
      • ' target='_blank'>3G/4G USB Modem Compatibility List
      • ' target='_blank'>Quick Installation Guide

  • Image (High Resolution)

  • SoftwareSoftware

    1. V1:
      • ' target='_blank'>Firmware
    2. V2:
      • ' target='_blank'>Firmware
    How to find the hardware version?
    For example: V1.6 = V1
