1U Rackmount Network Appliance with Intel 6th/7th/8th/9th Ge
Supports Intel 6th/7th/8th/9th Gen Core i9/i7/i5/i3, Pentium, Celeron, Xeon E3 12XX v5/v6 processors
Deploy Intel C236 or H110 express chipset
Supports 2 x DDR4 DIMM 2133MHz RAM, Max. 64GB(ECC/Non-ECC)
Supports 8 x Ethernet ports or 6 x Ethernet + 2 x SFP , supports Wake On LAN, PXE booting
Supports Max. 2 x expanded NIC
Supports 1 x RS232 console port(RJ45 type, Cisco Standard)
Supports 2 x USB 2.0 headers, 2 x USB 3.0 ports
Supports M-SATA SSD, CF, SATA HDD storage
Deploy Intel C236 or H110 express chipset
Supports 2 x DDR4 DIMM 2133MHz RAM, Max. 64GB(ECC/Non-ECC)
Supports 8 x Ethernet ports or 6 x Ethernet + 2 x SFP , supports Wake On LAN, PXE booting
Supports Max. 2 x expanded NIC
Supports 1 x RS232 console port(RJ45 type, Cisco Standard)
Supports 2 x USB 2.0 headers, 2 x USB 3.0 ports
Supports M-SATA SSD, CF, SATA HDD storage
| Model No. | FW-2381-2N | |
| Form Factor | 1U 19” Rackmount | |
| Platform | Processor Options |
Intel 6th/7th/8th/9th Gen Core i9/i7/i5/i3, Pentium, Celeron, Xeon E3 12XX v5/v6 processors |
| CPU Socket | 1 x LGA1151 | |
| Chipset | Intel C236 | |
| Security Acceleration | AES-NI | |
| BIOS | AMI SPI Flash BIOS | |
| System Memory | Technology | DDR4 2133 MHz |
| Max. Capacity | 64GB | |
| Socket | 2 x 288pin DIMM | |
| Networking | Ethernet Ports |
8 x Intel i211-AT GbE or Intel i225-V 2.5 GbE RJ45 ports, or 6 x Intel i211-AT GbE RJ45 + 2 x Intel i210-IS GbE SFP, or 6 x Intel i225-V 2.5GbE RJ45+ 2 x Intel i225-V + PHY 2.5GbE SFP 2 x NIC slots |
| Bypass | Optional | |
| I/O Interface | Reset Button | - |
| LED |
1 x Power LED 1 x HDD LED 1 x GPIO LED |
|
| Power Button | - | |
| Console | 1 x RJ45 | |
| USB | 2 x USB 3.0 | |
| LCD Module | - | |
| Display | 1 x VGA | |
| Power Input | AC power inlet on PSU | |
| Storage | HDD/SSD Support |
3 x 2.5'' bays(FW-2381-2NA/2NB) 4 x 2.5'' bays(FW-2381-2NC/2ND) |
| Onboard Storage | 1 x m-SATA, 1 x CF slot | |
| Expansion | PCIe | 1 x PCIe X16 |
| Mini-PCIe | 1 x Mini PCIe(For WiFi and 4G) | |
| Miscellaneous | Watchdog | 255 levels, 1 to 255 sec |
| Internal RTC with Li Battery | Yes | |
| TPM | - | |
| Cooling | Processor | CPU fan |
| System | 3 x System cooling fans | |
| Environmental Parameters | Temperature | 0℃～45℃/ -20℃～70℃ |
| Humidity | 5 ~ 95%, non condensing | |
| System Dimensions | (WxHxD) | 580x45x430mm |
| Weight | 8.3kg | |
| Package Dimensions | (WxHxD) | 580x180x760mm |
| Weight | 11KG | |
| Power | Type/Watts |
220W single ATX PSU 300W redundant ATX PSU(Optional) |
| Input | 90~264V@47~63Hz | |
| Approvals and Compliance | CE, FCC Class B | |
-
